FLAT CABLE 0.6/1kV Solid Copper Conductor Indoor Cable (Product Code: Flat Cables, Model: MYP-0-38-0-66KV-3x35-1x16) is a high-performance, flexible electrical cable engineered for reliable indoor power transmission in residential, commercial, and industrial applications. Designed and manufactured by East Energy Electrical Engineering Co., Ltd.—a professional enterprise specializing in electrical system R&D, power engineering, and energy solutions—this cable ensures safety, durability, and compliance with global standards, including TS9760, IEC227, VDE 0281, and BS6500. Its flat design optimizes space efficiency in installations, while robust construction guarantees long-term operation in demanding environments.
Premium Conductivity: Solid copper core ensures low electrical resistance (e.g., 18.1 Ω/km for 1 mm²) and efficient current transmission.
Enhanced Safety: PVC insulation and outer sheath provide dual protection against electrical leakage, dust, moisture, and minor mechanical impacts.
Space-Saving Design: Flat cable profile simplifies routing in tight spaces like cable ducts, trays, and concealed conduits.
Global Compliance: Meets international standards (IEC, VDE, BS), facilitating use in projects requiring certified components.
Flexible Application: Suitable for indoor wiring, industrial plants, switching stations, and underground installations (with additional mechanical protection).
| Num. of Cores & Cross Section | Wire Diameter (mm) | Insulation Thickness (mm) | Sheath Thickness (mm) | Conductor DC Resistance at 20℃ (Ω/km) | Approx. Weight (Kg/km) | Max. Current Capacity at 30℃ (Pipe A) | Max. Current Capacity at 30℃ (Air A) |
|---|---|---|---|---|---|---|---|
| 2 × 1 mm² | 1.1 | 0.6 | 0.8 | 18.1 | 50.0 | — | 19 |
| 2 × 1.5 mm² | 1.35 | 0.7 | 0.8 | 12.1 | 66.0 | 32 | 20 |
| 2 × 2.5 mm² | 1.73 | 0.8 | 1.0 | 7.41 | 104 | 42 | 20 |
| 2 × 4 mm² | 2.19 | 0.8 | 1.1 | 4.61 | 143 | 54 | 20 |
| 3 × 1 mm² | 1.1 | 0.6 | 0.8 | 18.1 | 73.0 | — | 20 |
| 3 × 1.5 mm² | 1.35 | 0.7 | 0.9 | 12.1 | 101 | 26 | 20 |
| 3 × 2.5 mm² | 1.73 | 0.8 | 1.1 | 7.41 | 158 | 34 | 20 |
| 3 × 4 mm² | 2.19 | 0.8 | 1.2 | 4.61 | 216 | 44 | 20 |
Operating Temperatures:
Maximum Continuous Operating Temperature: 70℃
Short-Circuit Withstand Temperature: 160℃ (up to 5 seconds)
Indoor Power Distribution: Residential/commercial building wiring, lighting circuits, socket connections.
Industrial Installations: Machinery power supply, control panels, switching stations, and plant electrification.
Structured Cabling Systems: Cable ducts, trays, conduits, and enclosed raceways.
Limited Underground Use: When protected by conduits or sleeves to prevent mechanical damage.
Reliability: Solid copper conductor and PVC layers ensure stable performance under 0.6/1kV rated voltage.
Certified Quality: Manufactured under strict compliance with IEC, VDE, and BS standards for global acceptability.
Cost-Effective: Lightweight design reduces shipping costs, while easy installation saves labor time.
Versatility: Available in 2-core and 3-core configurations (1–4 mm² cross-sections) to match diverse load requirements.
Manufacturer’s Expertise: Backed by East Energy’s 15+ years of experience in electrical engineering and custom solutions.
