The NYY cable features a multi-layer structure engineered for optimal performance:
It utilizes either solid or stranded copper conductors, chosen for their excellent electrical conductivity and mechanical strength. Solid conductors are ideal for applications requiring rigidity, while stranded conductors offer flexibility, making them suitable for installations with bending requirements.
A PVC insulation layer surrounds the conductor, providing effective electrical isolation. PVC is selected for its resistance to moisture, chemicals, and temperature variations, ensuring long-term insulation integrity.
The cable includes PVC filling to maintain structural stability, preventing internal components from shifting during installation or operation. An outer PVC sheath adds an extra layer of protection against external mechanical stress, corrosion, and environmental factors.
Maximum operating temperature: 70℃
Short-circuit temperature: 160℃
| Num.of Cores and Nominal Cross Section | Number and Dia.of wires (mm) | Thickness of insulation (mm) | Thickness of sheath (mm) | Conductor DC resistance at 20℃ (Ω/km) | Approx Total Weight (Kg/km) | Max. Current Carrying Capacity at 30℃ | |
|---|---|---|---|---|---|---|---|
| Pipe A | Air A | ||||||
| 1×4 | 2.19 | 1.0 | 1.4 | 4.61 | 87.0 | 45 | 37 |
| 1×6 | 2.68 | 1.0 | 1.4 | 3.08 | 109 | 57 | 48 |
| 1×10 | 7×1.32 | 1.0 | 1.4 | 1.83 | 166 | 78 | 66 |
| 1×16 | 7×1.68 | 1.0 | 1.4 | 1.15 | 234 | 103 | 89 |
| 1×25 | 7×2.19 | 1.2 | 1.4 | 0.727 | 341 | 137 | 118 |
| 2×1.5 | 1.35 | 0.8 | 1.8 | 12.1 | 127 | 32 | 20 |
| 2×2.5 | 1.73 | 0.8 | 1.8 | 7.41 | 160 | 42 | 27 |
| 2×4 | 2.19 | 1.0 | 1.8 | 4.61 | 233 | 54 | 37 |
| 2×6 | 2.68 | 1.0 | 1.8 | 3.08 | 295 | 68 | 48 |
| 2×10 | 7×1.32 | 1.0 | 1.8 | 1.83 | 469 | 90 | 66 |
| 2×16 | 7×1.68 | 1.0 | 1.8 | 1.15 | 652 | 116 | 89 |
| 3×1.5 | 1.35 | 0.8 | 1.8 | 12.1 | 148 | 26 | 18 |
| 3×2.5 | 1.73 | 0.8 | 1.8 | 7.41 | 191 | 34 | 25 |
| 3×4 | 2.19 | 1.0 | 1.8 | 4.61 | 280 | 44 | 34 |
| 3×6 | 2.68 | 1.0 | 1.8 | 3.08 | 361 | 56 | 43 |
| 3×10 | 7×1.32 | 1.0 | 1.8 | 1.83 | 579 | 75 | 60 |
| 3×16 | 7×1.68 | 1.0 | 1.8 | 1.15 | 820 | 98 | 80 |
| 4×1.5 | 1.35 | 0.8 | 1.8 | 12.1 | 178 | 26 | 18 |
| 4×2.5 | 1.73 | 0.8 | 1.8 | 7.41 | 241 | 34 | 25 |
| 4×4 | 2.19 | 1.0 | 1.8 | 4.61 | 246 | 44 | 34 |
| 4×6 | 2.68 | 1.0 | 1.8 | 3.08 | 456 | 56 | 43 |
| 4×10 | 7×1.32 | 1.0 | 1.8 | 1.83 | 731 | 75 | 60 |
| 4×16 | 7×1.68 | 1.0 | 1.8 | 1.15 | 1036 | 98 | 80 |
| 5×1.5 | 1.35 | 0.8 | 1.8 | 12.1 | 218 | 26 | 18 |
| 5×2.5 | 1.73 | 0.8 | 1.8 | 7.41 | 285 | 34 | 25 |
| 5×4 | 2.19 | 1.0 | 1.8 | 4.61 | 375 | 44 | 34 |
| 5×6 | 2.68 | 1.0 | 1.8 | 3.08 | 548 | 56 | 43 |
| 5×10 | 7×1.32 | 1.0 | 1.8 | 1.83 | 891 | 75 | 60 |
| 5×16 | 7×1.66 | 1.0 | 1.8 | 1.15 | 1276 | 98 | 80 |
The NYY PVC Insulated Cable is suitable for:
It performs reliably in indoor environments such as commercial buildings, offices, and residential complexes, where stable power distribution is essential.
Ideal for use in cable ducts and industrial facilities, the cable withstands the operational demands of machinery and equipment, ensuring consistent power supply.
Its robust design makes it a preferred choice for switching stations, where electrical safety and performance are critical.
It can be installed underground with additional protection, provided that the risk of mechanical damage is low.
